SIGNA™ Architect – 70 cm

Unleash

Clear advances with clear advantages

Now the potential for MR is even more astonishing with the SIGNA™ Architect, a state-of-the-art imaging solution that combines the advancements in MR technology with GE Healthcare's intuitive engineering. Fueled by the SIGNA™Works productivity platform, the SIGNA™ Architect is a harmonious design of form and function.

Welcome to the future of MR. Forge ahead with SIGNA™ Architect.

SIGNA™Works

The new standard is extraordinary

Our new SIGNA™Works platform redefines productivity.

SIGNA™Works is the fuel that drives your imaging to the next level and beyond. SIGNA™Works standard applications come pre-loaded with SIGNA™ Architect as a fully integrated solution. It's value-added technology that's upgradable and can be customized with additional applications to suit the needs of your growing practice.

Energize
Phenomenal exams to meet your clinical needs

The SIGNA™Works standard applications portfolio contains imaging solutions that cover a wide variety of contrasts, 2D and 3D volumetric data, including motion correction capabilities. SIGNA™Works provides all of the tools you need to complete a clinical exam.

Expand
Broaden your areas of expertise

Take your expertise to the next level when you move beyond the standard with SIGNA™Works innovative applications. Improved image quality, higher efficiency and a more streamlined workflow help you perform better than ever before.

  • BodyWorks

    With BodyWorks, we address one of the fastest growing areas in MR. This all-inclusive library allows you to image abdominal and pelvic anatomy with user flexibility to adapt to different patient types.

    Auto Navigator is GE's solution to combat respiratory motion in abdominal imaging. This free-breathing approach is compatible with multiple pulse sequences including diffusion, PROPELLER MB, MRCP and dynamic T1 imaging.
  • CVWorks

    With our intuitive cardiac techniques, you can assess morphology, flow, function and tissue viability plus gain crucial insights into vascular structure and flow dynamics. CVWorks provides the flexibility to adapt to different patient types with exams that vastly simplify workflow.

    With CVWorks, multi breath-hold imaging can be a thing of the past. Our latest Single shot MDE and Black Blood techniques provide patient-friendly alternatives to uncomfortable breath-holds.

    With our workflow-simplified QuickStep protocols, scanning whole body vasculature can be done in less than 6 minutes. High performance gradients allow bright blood pool and myocardial tissue contrast on Cine FIESTA while preserving spatial resolution.
  • NeuroWorks

    This one-stop solution enables you to imagine brain, spine, vascular and peripheral nerve anatomy with exceptional tissue contrast. These motion-insensitive techniques feature single-click auto alignment, providing the complete neuro solution from scanning to post processing.

    NeuroWorks also includes Cube, our 3D volumetric imaging suite, standard with every system. This application allows you to suppress CSF and either white or gray matter to increase lesion conspicuity.

    PROPELLER MB, our latest PROPELLER enhancement, is a multi-shot approach that preserves tissue contrast regardless of weighting while also reducing motion artifacts. Additionally, this new technique introduces new contrasts such as T1 FSE.
  • OncoWorks

    This extensive library of techniques captures anatomic and morphologic data to uniquely enable oncological assessment of anatomy. OncoWorks includes robust tissue contrast, motion-insensitive, high temporal and spatial resolution imaging.

    3D volumetric imaging with an optimized adiabatic fat suppression, combined with ARC or ASSET, provides high spatial and temporal resolution to capture contrast uptake patterns. The FSPGR Ax Dynamic image shows lesion characteristics generated using AW VS7's positive enhancement map. The T2 PROPELLER image demonstrates small FOV and motion-correction through the prostate.
  • OrthoWorks

    This one-stop solution enables you to image brain, spine, vascular and peripheral nerve anatomy with exceptional tissue contrast. Includes ReadyBrain for single-click auto alignment, enabling patient planning through post processing.

    This extensive library of musculoskeletal imaging techniques enables you to image bone, joint and soft tissue with remarkable tissue contrast.

    OrthoWorks also includes 3D volumetric Cube with proton-density, combined with ASPIR, which enables improved fat suppression uniformity, which is routinely done as three separate 2D scans. With one 3D acquistion and multi planar reformats, Cubes may replace individual 2D scans.
  • PaedWorks

    Pediatric imaging requires exclusive and distinctive imaging techniques that provide ease of use for the user and clinical excellence for your smallest, most fragile patients.

    PaedWorks provides specialized protocols to simply address the needs of your smallest, most fragile patients. Techniques such as PB Navigators combined with PROPELLER MB are used with advanced techniques like diffusing imaging, allowing for patient-friendly, entirely free-breathing exams. Additionally, cardiac exams using single shot MDE provide faster, more reliable results.

    The four images demonstrate dynamic T1 imaging with PB Navigator, which enables the patient to breathe freely while capturing contrast in fast temporal phases. Whole spine evaluation can be obtained simply with routine T2 frFSE imaging.

Elevate

Raise your MR performance to new heights with groundbreaking technology

Designed to overcome barriers, SIGNA™ Architect's cutting edge platform makes it one of the most versatile, adaptable and powerful systems available from GE. Now feet-first, whole-body coverage is made easy. Dynamic yet insightful, the SIGNA™ Architect is MR built to work for you.

Total Digital Imaging (TDI)

The SIGNA™ Architect offers startling advances in imaging and a total imaging win with TDI.

product-product-categories-magnetic-resonance-imaging-signa artist-digital_imaging.jpg

GE's Direct Digital Interface (DDI) employs an independent analog-to-digital converter to digitize inputs from each of 128 RF channels, eliminating unnecessary noise enhancement.

eMode technology replaces analog blocking circuits with intelligent ultra-fast switches which further expand zero TE imaging capabilities.

product-product-categories-ultrasound-signa architect-banner images-channel_head_coil.jpg

48 Channel Head Coil and Coil Suite

Introduced with the SIGNA™ Architect, the optional 48 Channel Head Coil delivers phenomenal performance for every patient, with a fit-adaptable design that addresses 99.99% of the population while preserving the highest SNR and supporting advanced imaging capabilities such as HyperWorks technologies.

product-product-categories-ultrasound-signa architect-banner images-dockable_table.jpg

eXpress Dockable Table

The SIGNA™ Architect's eXpress table, with a memory foam surface, delivers feet-first or head-first imaging for everyone. With its detachable egress, you never have to worry about how quickly you can exit the MR suite. And with IntelliTouch positioning, just touch the edge of the table to position your patients.

product-product-categories-magnetic-resonance-imaging-signa artist-fov_img.jpg

FOV

In addition to accommodating larger patients, full 50x50x50cm FOV in a 70cm wide bore allows you to properly image off-center anatomy such as shoulders and hips. The SIGNA™ Architect's phenomenal homogeneity enables our largest FOV ever.

product-product-categories-ultrasound-signa architect-banner images-refine_img.jpg

reFINE and deFINE

With reFINE, the challenge of 3.0T high-yield uniformity has finally met its match. reFINE allows you to increase your control over improved RF pulse efficiency, so you get clearer, crisper signals no matter your patient composition or position.

deFINE takes the results of SIGNA™ Architect to the next level by enhancing the image appearance with integrated inline optimizable settings. These settings can be generated for each individual sequence or for the entire exam.
