| Document | Worksheet |
| System Voltage Regulation Calculator | DOC2287871 Rev 2 |
GE's family of multi-slice products allows you to match the product to your imaging needs.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Connectivity Requirements | Connectivity Form CT | ||||
| Connectivity Requirements | Connectivity Form CT&EHL | ||||
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing |
| Discovery CT590 RT&Optima CT580 w/1700 Table | 6-82D | 6-82R | 6-82RV | 5366636-1EN |
6-82f |
| Discovery CT590 RT&Optima CT580 w/HC Table | 6-84D | 6-84R | 6-84RV | 5366636-1EN | 6-84f |
| Revolution ACTs 8 Slice | 6-108D | 6-108R | 6-108RV | 5487112-1EN | 6-108f |
| Revolution ACT/ACTs 16 Slice | 6-110D | 6-110R | 6-110RV | 5487127-1EN | 6-110f |
| Revolution Ascend w/ 1700 Table | 6-128D | 5987663-1EN | 6-128f | ||
| Revolution Ascend w/ 2000 Table | 6-126D | 5987663-1EN | 6-126f | ||
| Revolution Vibe/Apex/Apex Elite | 6-120D | 5418654-1EN | 6-120f | ||
| Revolution CT/ES | 6-106D | 6-106R | 6-106RV | 5418654-1EN | 6-106f |
| Revolution Frontier w/1700 Table | 6-116D | 6-116R | 6-116RV | 5786386-1EN | 6-116f |
| Revolution Frontier w/2000 Table | 6-118D | 6-118R | 6-118RV | 5786386-1EN | 6-118f |
| Revolution Maxima w/1700 Table | 6-122D | 5809942-1EN | 6-122f | ||
| Revolution Maxima w/Lite Table | 6-124D | 5809942-1EN | 6-124f | ||
| Revolution Maxima w/2000 Table | 6-130D | 5809942-1EN | 6-130f | ||
| Revolution RT w/1700 Table | 6-134D | 5938483-1EN | 6-134f | ||
| Revolution RT w/High Capacity Table | 6-132D | 5938483-1EN | 6-132f | ||
GoldSeal has refurbished imaging technology to meet your needs and your budgets.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Radiography Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing | |
| Definium 5000 | 1-136 | 1-136 | 5192967-100 | 1-136f | ||
| Definium 6000 | 1-166 | 1-166 | 5343941-8EN | |||
| Definium 8000 | 1-134 | 1-134 | 5137435-100 | 1-134f | ||
| Definium 8000 FLEXI-DT | 1-138 | 1-138 | 5137435-100 | |||
| Discovery XR650 | 1-140 | 1-140 | 1-140R | 1-140RV | 5308113 | 1-140f |
| Discovery XR656 | 1-144 | 1-144R | 1-144RV | 5343949 | 1-144f | |
| Discovery XR656 Plus | 1-154 | 1-154R | 1-154RV | 5643834-1EN | 1-154f | |
| Optima XR640 | 1-142 | 1-142 | 1-142R | 1-142RV | 5308127 | 1-142f |
| Optima XR646 | 1-150 | 1-150R | 1-150RV | 5643854-1EN | 1-150f | |
| Proteus XR/a | 1-124 | 1-124 | 1-124R | 1-124RV | 2260326-100 | 1-124f |
| Proteus XR/f AT | 1-160 | DOC1913363 | 1-160f | |||
| Proteus XR/f ET | 1-162 | DOC1913363 | 1-162f | |||
| Proteus XR/f ST | 1-174 | DOC1913363 | 1-174f | |||
| Revolution XR/d 2X Platform | 1-132 | 1-132 | 5115585-100 | 1-132f | ||
| Silhouette VR | 1-120 | 1-120 | 2229353-100 | 1-120f | ||
| XR6000 | 1-158 | 5275600-100 | 1-158f |
| R&F Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing | ||
| Advantx HF/Legacy | 2-50 | 2-50 | 2144928-100 Rev 11 | 2-50f | |||
| Connexity | 5476009-1EN | ||||||
| Precision 500D | 2-54 | 2-54 | 2297165-100 | 2-54f | |||
| Precision 500D with Saturn Console | 2-60 | 2-60 | 2-60R | 2-60RV | 5436429-1EN | 2-60f | |
| Precision 500D with Magic PC | 2-58 | 2-58 | 2-58R | 2-58RV | 5181746-100 | 2-58f | |
| Precision MP/i | 2-56 | 2-56 | 2404435-100 | 2-56f | |||
| Precision RX/i | 3-50 | 3-50 | 5123449-100 | 3-50f | |||
| Related Products | Manual | ||||||
| SG80 and SG120 Chest Units | S0012533 Rev 2 | ||||||
| Interventional Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing | |
| Interventional Cardiology | ||||||
| Single Plane Innova IGS 530 (Cerber B) | 5-118 | 5730939-1EN | 5-118f | |||
| Single Plane Innova IGS 530 (Cerber A) | 5-106 | 5-106 | 5-106R | 5-106RV | 5499972-1-1EN |
5-106f |
| Bi-Plane Innova IGS 620 (Cerber B) | 5-122 | 5750182-1EN | 5-122f | |||
| Bi-Plane Innova IGS 620 (Cerber A) | 5-114 | 5-114R | 5-114RV | 5694389-1-1EN |
5-114f | |
| Interventional Radiology | ||||||
| Single Plane Innova IGS 540 (Cerber A) | 4-68 | 4-68 | 4-68R | 4-68RV | 5499972-1-1EN |
4-68f |
| Bi-Plane Innova IGS 630 (Cerber B) | 5-122 | 5750182-1EN | 5-122f | |||
| Bi-Plane Innova IGS 630 (Cerber A) | 4-72 | 4-72R | 4-72RV | 5694389-1-1EN |
4-72f | |
| Electrophysiology (EP) | ||||||
| Single Plane Innova IGS 520 (Cerber B) | 5-118 | 5730939-1EN | 5-118f | |||
| Single Plane Innova IGS 520 (Cerber A) | 5-110 | 5-110 | 5-110R | 5-110RV | 5499972-1-1EN |
5-110f |
| Bi-Plane Innova IGS 620 (Cerber B) | 5-122 | 5750182-1EN | 5-122f | |||
| Bi-Plane Innova IGS 620 (Cerber A) | 5-114 | 5-114R | 5-114RV | 5694389-1-1EN |
5-114f | |
| Discovery IGS | ||||||
| Please contact 877-305-9677 for additional information | ||||||
| Discovery IGS OR (Cerber A) | 4-88 | 4-84R | 4-84RV | 5507046-1-1EN |
4-88f | |
| Discovery IGS IR (Cerber B) | 4-108 | 5730951-1EN | 4-108f | |||
| Discovery IGS IR (Cerber A) | 4-92 | 4-84R |
4-84RV | 5507046-1-1EN |
4-92f | |
| Discovery IGS IR w/ Arm Panning (Cerber A) | 4-96 | 4-84R |
4-84RV | 5507046-1-1EN |
4-96f | |
| Single-Plane Innova 2100/3100/4100 Plus | 5-90 | 5-90 | 5-90R | 5-90RV | 5314528-4-1EN | 5-90f |
| Single-Plane Cardiology Innova 2100/3100/4100 Unity | 5160944-13-1EN | 5-82f | ||||
| Single-Plane - Radiology Innova 2100/3100/4100 Unity | 4-58 | 4-58 | 4-58R | 4-58RV | 5160944-13-1EN | 4-58f |
| Single-Plane Innova 3100-IQ Optima (IR) | 4-64 | 4-64 | 5314528-4-1EN |
4-64f | ||
| Innova Optima CL 323i | 4-80 | 4-80 | 4-80R | 4-80RV | 5491029-1-1EN |
4-80f |
| Bi-Plane Innova 2121/3131 (IR) | 5-84 | 5-84 | 5-84R | 5-84RV | 5177951-4-100 Rev 1 |
5-84f |
| Bi-Plane Innova 2121/3131 (IC) | 5177951-4-100 Rev 1 | 4-60f | ||||
| Bi-Plane Innova 2121/3131 (EP) | 5-88 | 5-88 | 5177951-4-100 Rev 1 |
5-88f | ||
| Single-Plane - Electrophysiology (EP) Innova 2100/3100/4100 Unity | 5-86 | 5-86 | 5160944-13-1EN | 5-86f | ||
| Hybrid OR | 5-94 | 5-94 | 5314528-4-1EN | 5-94f | ||
| Innova 2000 | 5-80 | 5-80 | 2337741-100 Rev 5 | 5-80f | ||
| MR Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing | |
| Discovery MR450 1.5T | 8-226 | 8-226 | 8-226R | 8-226RV | 5500109 | 8-226f |
| Discovery MR750 3.0T | 8-222 | 8-222 | 8-222R | 8-222RV | 5500101 | 8-222f |
| Optima MR360 / Brivo MR355 (New Enclosure) | 8-250 | 8-250 | 8-250 |
8-250RV | 5433834-1EN | 8-250f |
| Optima MR360 / Brivo MR355 (Old Enclosure) | 8-238 | 8-238 | 8-238R | 8-238RV | 5338503 Rev 6 | 8-238f |
| ONI Optima 1.5T MR430s Extremity | 8-234 | 8-234 | 8-234R | 8-234RV | DOC0797563 | 8-234f |
| ONI 1.0T Extremity | 2000-9304 Rev C | |||||
| Signa Excite HD 1.5T | 8-186 | 8-186 | 5133301 | 8-186f | ||
| Signa Excite HD 3.0T | 8-194 | 8-194 | 5133303 | 8-194f | ||
| Signa HDe 1.5T with Type A Cooling, Cold Head Compressor Outside | 8-198 | 8-198 | 5143464 | 8-198f | ||
| Signa HDe 1.5T with Type B Cooling, Cold Head Compressor Inside | 8-202 | 8-202 | 5143464 | 8-202f | ||
| Signa HDx, HDxt, HDi, Vibrant 1.5T | 8-206 | 8-206 | 5159901 | 8-206f | ||
| Signa HDx, HDxt Twinspeed 1.5T | 8-210 | 8-210 | 5159902 | 8-210f | ||
| Signa HDx, HDxt 3.0T | 8-214 | 8-214 | 5159903 | 8-214f | ||
| Signa MR/i 1.5T Excite | 8-136 | 8-136 | 2223170 | 8-136f | ||
| Signa Ovation HD 0.35T | 8-218 | 8-218 | 5165376 | |||
| Signa Profile HD 0.2T | 8-66 | 8-66 | 5196540 Rev 3 | 8-66f |
| NM/PET Products | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing | |
| Nuclear Medicine Products | ||||||
| Discovery NM 530c | 7-70 | 7-70R | 7-70RV | 5454095-1EN | 7-70f | |
| Infinia 2 | 7-62 | 7-62 | 2411013-100 Rev 3 | 7-62f | ||
| Infinia 2 w/Hawkeye Option | 7-64 | 7-64 | 2411013-100 Rev 3 | 7-64f | ||
| Infinia 2 w/Hawkeye 4 | 7-68 | 7-68 | 7-68R | 7-68RV | 5167775-100 | 7-68f |
| Optima NMCT 640 | 7-84 | 7-84 | 7-84R | 7-84RV | 5426783-1EN |
7-84f |
| Ventri System w/Premium Table | 7-66 | 7-66 | 7-66R | 7-66RV | 2414305-100 Rev 3 | 7-66f |
| PET Products |
||||||
| Discovery PET/CT 610/710 (64 Slice) | 12-28 | 12-28 | 12-28R | 12-28RV | 5433542-1EN | 12-28f |
| Optima PET/CT 560/560FX - Discovery PET/CT 610/710 (16 Slice) | 12-26 | 12-26 | 12-26R | 12-26RV | 5433542-1EN | 12-26f |
| Discovery PET/CT 600 | 12-18 | 12-18 | 12-18R | 12-18RV | 5266541-1EN | 12-18f |
| Discovery PET/CT 690 | 12-20 | 12-20 | 12-20R | 12-20RV | 5266541-1EN | 12-20f |
| Discovery PET/CT 690 Elite | 12-22 | 12-22 | 12-22R | 12-22RV | 5266541-1EN | 12-22f |
| Optima PET/CT 560 | 12-24 | 12-24 | 12-24R | 12-24RV | 5266541-1EN | 12-24f |
| Discovery LS | 12-10 | 12-10 | 2317947-100 | 12-10f | ||
| Discovery ST | 12-12 | 12-12 | 2341917-100 | 12-12f | ||
| Discovery STE & RX HP60 | 12-14 | 12-14 | 12-14R | 12-14RV | 5141127-100 | 12-14f |
| Discovery VCT | 12-16 | 12-16 | 12-16R | 12-16RV | 5166283-100 | 12-16f |
| Womens Health Product | DWG | 3D PDF | BIM (Revit) |
PreInstall Manual | Typical Final Drawing | |
| Diamond System | 9-30 | 9-30 | 9-30f | |||
| Performa System | 9-28 | 9-28 | 9-28f | |||
| SenoClaire | 9-34 | 9-34 | 9-34R | 9-34RV | 5415897-5-8EN Rev 1 | 9-34f |
| Senographe 700T/800T | 9-18 | 9-18 | 2148333-100 | 9-18f | ||
| Senographe 2000D | 9-24 | 9-24 | 5128704-1-100 | 9-24f | ||
| Senographe Crystal | 9-36 | 9-36 | 5511226-8EN | 9-36f | ||
| Senographe Crystal Nova | 5673206-8EN Rev 4 | |||||
| Senographe DMR/Senovision/Dataflash | 9-22 | 9-22 | 5128706-1-100 | 9-22f | ||
| Senographe DS | 9-26 | 9-26 | 2385057-10-8EN | 9-26f | ||
| Senographe Essential | 9-32 | 9-32 | 9-32R | 9-32RV | 5160036-12-8EN | 9-32f |
| CT Product | DWG | 3D PDF | BIM (Revit) |
PreInstall Manual | Typical Final Drawing | |
| Brivo CT315/325 | 6-86 | 6-86 | 6-86R | 6-86RV | 5306512-1EN | 6-86f |
| Brivo CT385 | 6-92 | 6-92 | 6-92R | 6-92RV | 5426299-1EN | 6-92f |
| CardioGraphe | 6-114 | 5721172-1EN | 6-114f | |||
| Optima CT 520 1.5 | 6-94 | 6-94R | 6-94RV | 5447459-1EN | 6-94f | |
| Optima CT 540 | 6-90 | 6-90R | 6-90RV | 5341627-1EN | 6-90f | |
| BrightSpeed Elite Enhanced | 6-72 | 6-72 | 5341627-1EN | 6-72f | ||
| BrightSpeed Select | 6-62 | 6-62 | 6-62R | 6-62RV | 5181595-100 | 6-62f |
| BrightSpeed Elite, Edge, Excel | 6-58 | 6-58 | 5141177-100 | 6-58f | ||
| LightSpeed VCT w/1700 Table, 7x System (32 and 64 Slice) | 6-54 | 6-54 | 6-54R | 6-54RV | 5116410-100 | 6-54f |
| LightSpeed VCT w/2000 Table, 7x System (32 and 64 Slice) | 6-56 | 6-56 | 6-56R | 6-56RV | 5116410-100 | 6-56f |
| LightSpeed RT16, Xtra (16 Slice) w/1700 Table | 6-64 | 6-64 | 5177460-100 | 6-64f | ||
| LightSpeed RT16, Xtra (16 Slice) w/2000 Table | 6-66 | 6-66 | 5177460-100 | 6-66f | ||
| Lightspeed RT16/Xtra (16 Slice) w/ Bariatric Table | 6-76 | 6-76 | 5177460-100 | 6-76f | ||
| Optima CT 660/660 Pro w/1700 Table | 6-78 | 6-78 | 6-78R | 6-78RV | 5368510-1EN | 6-78f |
| Optima CT 660/660 Pro w/2000 Table | 6-80 | 6-80 | 6-80R | 6-80RV | 5368510-1EN | 6-80f |
| Revolution CT 1.0 | 6-96 | 6-96 |
6-96R | 6-96RV | 5418654-1EN | 6-96f |
| Revolution Discovery CT GSI/HD and 750 HD w/1700 Table | 6-102 | 6-102R | 6-102RV | 5220253-1EN | 6-102f | |
| Revolution Discovery CT GSI/HD and 750 HD w/2000 Table | 6-104 | 6-104R | 6-104RV | 5220253-1EN | 6-104f | |
| Revolution EVO w/1700 Table | 6-98 | 6-98R | 6-98RV | 5866663-1EN | 6-98f | |
| Revolution EVO w/2000 Table | 6-100 | 6-100R | 6-100RV | 5866663-1EN | 6-100f | |
| VEO System w/Discovery CT750 HD | 6-88 | 6-88 | 5395804-1EN | VEO |
| Ultrasound Product | DWG | PreInstall Manual | |
| LOGIQ 700 Expert | Logic 700 | 46-030405 Rev 4 | |
| LOGIQ 700 Pro | Logic 700 | 46-030405 Rev 4 | |
| LOGIQ 500 | Logic 500 | p9030ta | |
| Voluson Women's Health | Voluson |
Our clinically relevant products help physicians perform interventional procedures.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Connectivity Requirements | Connectivity Form Vascular ISG | ||||
| Flooring Application Vendors | Vendor Listing | ||||
| Floor Pre-Installation Kit Procedure | 5985495-199 | ||||
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing |
| Interventional Cardiology | |||||
| Allia IGS Pulse 3/5 | 5-142D | 5914487-8EN | 5-142f | ||
| Allia IGS 3/5 with AutoRight | 5-138D | 5871351-8EN | 5-138f | ||
| Single Plane Innova IGS 5 with AutoRight | 5-126D | 5813633-8EN | 5-126f | ||
| Single Plane Innova IGS 3 with AutoRight | 5-134D | 5813633-8EN | 5-134f | ||
| Bi-Plane Innova IGS 6 with AutoRight | 5-130D | 5813644-8EN | 5-130f | ||
| Optima IGS 320 and 330 System | 4-100D |
4-100R |
4-100RV | 5537562-1-1EN | 4-100f |
| Interventional Radiology | |||||
| Allia IGS Pulse 3/5 | 5-142D | 5914487-8EN | 5-142f | ||
| Allia IGS 3/5 with AutoRight | 5-138D | 5871351-8EN | 5-138f | ||
| Single Plane Innova IGS 5 with AutoRight | 5-126D | 5813633-8EN | 5-126f | ||
| Bi-Plane Innova IGS 6 with AutoRight | 5-130D | 5813644-8EN | 5-130f | ||
| Electrophysiology (EP) | |||||
| Allia IGS Pulse 3/5 | 5-142D | 5914487-8EN | 5-142f | ||
| Allia IGS 3/5 with AutoRight | 5-138D | 5871351-8EN | 5-138f | ||
| Single Plane Innova IGS 5 with AutoRight | 5-126D | 5813633-8EN | 5-126f | ||
| Bi-Plane Innova IGS 6 with AutoRight | 5-130D | 5813644-8EN | 5-130f | ||
| Allia/Discovery IGS 7 | |||||
| Allia Moveo | 4-134D | 5956559-8EN | 4-134f | ||
| Allia IGS Pulse 7 (IR/OR) | 4-132D | 5914504-8EN | 4-132f | ||
| Allia IGS 7 (IR) | 4-124D | 5847738-8EN | 4-124f | ||
| Allia IGS 7 (OR) | 4-128D | 5847738-8EN | 4-128f | ||
| Discovery IGS 7 (IR) with AutoRight | 4-116D | 5813615-8EN | 4-116f | ||
| Discovery IGS 7 (OR) with AutoRight | 4-120D | 5813615-8EN | 4-120f | ||
| Suspension Information | |||||
| Innova IGS Single Plane Open Monitor Suspension | 5335951-2-1EN Rev 1 | ||||
| Innova IGS Bi Plane Open Monitor Suspension | 5499175-1-1EN | ||||
| Discovery IGS Open Monitor Suspension | 5442831-4-1EN | ||||
| Innova Systems | |||||
| Pre-Installation Kit Procedures | 5745300-1EN | ||||
| Hemodynamics (Patient Monitoring) | |||||
| MacLab-CardioLab | 2063076-007 | ||||
When you demand more accuracy, more productivity and more support, GE HealthCare delivers.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Product | 3D PDF | BIM (Revit) |
| Labor and Delivery | L&D | L&D |
| Free Standing Panda Warmer | Free Standing | Free Standing |
| Wall Mounted Panda Warmer | Wall Mounted | Wall Mounted |
| Neonatal Intensive Care (NICU) | NICU | NICU |
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing | |
| Lunar iDXA | B-2 | B-2 | B-2R | B-2RV | LU46003EN | |
| Lunar Prodigy | B-4 | B-4 | B-4R | B-4RV | LU46003EN | |
| Lunar Compact Prodigy | B-6 | B-6 | B-6R | B-6RV | LU46003EN | |
| Lunar Aria | B-8 | B-8 | LU46005EN |
| Product Data Sheets | |
| Lunar iDXA with Advance Package Spec Sheet | General Information |
| Lunar iDXA with Pro Package Spec Sheet | General Information |
| Lunar Prodigy Pro Package Spec Sheet | General Information |
| DPX Bravo Spec Sheet | General Information |
| DPX Duo Spec Sheet | General Information |
| DPK NT Spec Sheet | General Information |
| Safety And Specifications | Safety and Specs |
When you demand more accuracy, more productivity and more support, GE Healthcare delivers.
GE Healthcare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE Healthcare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Connectivity Requirements | Connectivity Form MR | ||||
| RF and Magnetic Shielding Vendors | Associates Listing | ||||
| Vibration Testing Consultants | Associates Listing | ||||
| Additional Preinstallation Requirements | Manual | ||||
| RF Shielded Room Requirements | 5850260-1EN | ||||
| IEC Electromagnetic Compatibility | 5850261-1EN | ||||
| Acoustic Room Details | 5850262-1EN | ||||
| Magnet Room Venting | 5850263-1EN | ||||
| Magnet Venting Conformance Assessment Form | DOC2705036 | ||||
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing |
| Signa Sprint Select 1.5T | 8-338D | 5997483-8EN | 8-338f | ||
| Signa Sprint Select 1.5T with Freelium | 8-342D | 5997485-8EN | 8-342f | ||
| Signa Bolt 3.0T | 8-338 | 5983160-8EN | 8-338f | ||
| Signa PET-MR 3.0T (UA Magnet) | 8-262D | 8-262R | 8-262RV | 5480759 | 8-262f |
| Signa PET-MR 3.0T (AR Magnet) | 8-326D | 5480759 | 8-326f | ||
| Signa Artist 1.5T (Platform Configuration) | 8-306D | 5670001 | 8-306f | ||
| Signa Artist 1.5T (Legacy Configuration) | 8-282D | 5936619-1EN | 8-282f | ||
| Signa Artist Evo 1.5T | 8-294D | 5884915-8EN | 8-294f | ||
| Optima MR450w 1.5T | 8-230D | 8-230R | 8-230RV | 5936619-1EN | 8-230f |
| Signa Architect (Platform Configuration) | 8-322D | 5670003 | 8-322f | ||
| Signa Architect, Discovery MR750w 3.0T (UA Magnet - Legacy configuration) | 8-246D |
8-246R | 8-246RV | 5671000-8EN | 8-246f |
| Signa Champion 1.5T | 8-314D | 5941081-8EN | 8-314f | ||
| Signa Creator / Signa Explorer 1.5T | 8-254D |
8-254R | 8-254RV | 5538857-1EN |
8-254f |
| Signa Hero 3.0T | 8-290D | 5852803-1EN | 8-290f | ||
| Signa Pioneer 3.0T | 8-266D |
8-266R | 8-266RV | 5680003-1EN | 8-266f |
| Signa Premier XT 3.0T | 8-274D |
8-274RV | 5815067 | 8-274f | |
| Signa Premier 3.0T (Site neutral) | 8-298D | 5815067 | 8-298f | ||
| Signa Prime 1.5T | 8-286D | 5538858-1EN | 8-286f | ||
| Signa Victor 1.5T | 8-302D | 5917976-8EN | 8-302f | ||
| Signa Voyager 1.5T | 8-278D |
5680008-1EN |
8-278f | ||
| Signa Voyager 1.5T (classic enclosure) | 8-270D | 8-270R | 8-270RV | 5680008-1EN | 8-270f |
| Signa 7T | 8-334D | 5809186 | 8-334f | ||
| Signa Sprint Elite 1.5T | 8-330D | 5982837-8EN | 8-330f | ||
| Supplement to GE Healthcare PIMs - Guidance for customer supplied main disconnect panel (MDP) | Manual | ||||
| Signa Pioneer, Signa Voyager, Signa Creator/Explorer, Discovery 750w, Optima 450w | 5835423-8EN | ||||
| Product Upgrades | Manual | ||||
| Signa Excite HDx 1.5T Upgrade | 5159904 | ||||
| Signa Excite HDx 3.0T Upgrade | 5159905 | ||||
| MR Storage Requirements | Manual | ||||
| Storage Requirements | 5182674 | ||||
| MR Magnet Handling and Pre-Delivery Requirements | Manual | ||||
| 1.5T PM Series Magnet Handling Manual | 5807458-1EN | ||||
| 1.5T R Series Magnet Handling Manual | 5836628-1EN | ||||
| 1.5T RD Series Magnet Handling Manual | 5836619-1EN | ||||
| 1.5T HM Series Magnet Handling Manual | 5836617-1EN | ||||
| 3.0T AR Series Magnet Handling Manual | 5869669-1EN | ||||
| 3.0T UA Series Magnet Handling Manual | 5836648-1EN | ||||
| 3.0T W, WB Series Magnet Handling Manual | 5836649-1EN |
||||
| Signa Pioneer / Voyager / Hero Pre-Delivery | 5728068-1EN |
||||
| MR450, MR750, MR450w/Artist, and MR750w/Architect Pre-Delivery | 5500097 | ||||
| Signa Premier Pre-Delivery | 5791338 | ||||
| Cooling Requirements | Manual | ||||
| Signa Artist/Optima MR450w | Dimplex WO2-2-5000 manual |
||||
| Dimplex GO2-2-5000 manual |
|||||
| SIGNA Architect, Discovery MR450, Discovery MR750, Discovery MR750w, Signa Sprint Elite | Dimplex WO2-2-7500 manual |
||||
| Dimplex GO2-2-10000 manual |
|||||
| Signa Premier XT | Dimplex WO2-2-10000 manual | ||||
| Dimplex GO2-2-10000 manual | |||||
| SIGNA Pioneer, SIGNA Voyager, SIGNA Hero, SIGNA Champion | Dimplex WO2-7500 manual |
||||
| Dimplex GO2-7500 manual |
|||||
| Signa Creator/Signa Explorer / Optima M360/Brivo MR355 Cooling | 355/360 Chillers |
||||
| Multiple Products | KKT’s website |
||||
Your patient monitoring needs can be found here.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Product | |
| CARESCAPE Monitor B650 | B650 Cut Sheet.pdf |
| CARESCAPE Monitor B850 | B850 Displays Cut Sheet.pdf B850 spec sheet.pdf |
| CIC Pro Clinical Information Center | CICV5 Spec Sheet.pdf |
| Network Equipment Installation | Network Equipment Installation.pdf |
Our products lead the way to help solve the most challenging dilemmas facing nuclear medicine.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
The Precision family offers quality imaging for both traditional and emerging applications.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Connectivity Requirements | Connectivity Form XR | ||||
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing |
| Precision 180, Discovery RF180 | 2-70D |
5793724-1EN |
2-70f | ||
| Precision 600, Precision 600FP | 2-62D |
5756081-1EN | 2-62f | ||
| Precision CRF | 2-72D | 5884474-1EN | 2-72f | ||
| Precision Thunis 800+ | 2-68D | 5442442-1EN | 2-68f | ||
| Optima RF420 | 2-64D |
5725001-8EN Rev 1 |
2-64f | ||
| Optima RF420 Non-Elevating |
2-66D |
5725001-8EN Rev 1 | 2-66f | ||
| Wireless DR Imaging Option | 5397208-8EN | ||||
| AeroDR Implementation | KMMI-137 | KM-Upgrd | |||
GE HealthCare has a Radiography system solution that meets your throughput goals and budget constraints.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Connectivity Requirements | Connectivity Form XR | ||||
| Connectivity Requirements | Connectivity Form XRF | ||||
| Connectivity Requirements | Connectivity Form Mobile XR | ||||
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing |
| Definium Pace Select ST | 1-186D | 5649146-8EN | 1-186f | ||
| Definium Pace Select ET | 1-188D | 5650146-8EN | 1-188f | ||
| Definium Tempo Plus/Pro | 1-182D | 5743002-1EN | 1-182f |
||
| Definium Tempo Select | 1-190D | 6743002-8EN | 1-190f | ||
| Definium 656 HD, Discovery XR656 HD | 1-168D | 5643942-1EN | 1-168f | ||
| Definium 646 HD, Optima XR646 HD | 1-170D | 5643972-1EN | 1-170f | ||
| Definium 646 HD Standard, Optima XR646 HD Standard |
1-164D | 5643972-1EN | 1-164f | ||
| Brivo XR385 (DR-F) | 1-146D |
1-146R | 1-146RV | 5265603-1EN | 1-146f |
| Brivo XR575 | 1-176D | 5429555-PI-1EN | 1-176f | ||
| Definium XR6000 Gen 3, XR 6000 VRS, XR 6000 Starlight | 1-172D |
5549138-2EN | 1-172f | ||
| Definium XR6000 Gen 4 | 1-184D | 5649141-8EN | 1-184f | ||
| Definium XR/f ET | 1-178D | 5847504-1EN Rev 5 | 1-178f | ||
| Definium XR/f ST | 1-180D | 5847504-1EN Rev 5 | 1-180f | ||
| Brivo XR118 | 5461785-8EN | ||||
| Wireless DR Imaging Option | 5397208-8EN | ||||
| AeroDR Implementation | KMMI-137 | KM-Upgrade | |||
| Product | |
| Administrator Guide for AW Server | Administrator Guide |
| Product Data Sheets for AW Server | Product Data Sheets |
| Project Implementation Guide for MR Systems | MR Project Implementation Guide |
| Project Implementation Guide for CT, PET/CT, X-Ray, and Nuclear Systems | CT, PET/CT, X-Ray, Nuclear Project Implementation Guide |
| Project Implementation Guide for Interventional Systems | Interventional Project Implementation Guide |
| DCAR Project Implementation Guide | DCAR Project Implementation Guide |
| CARESCAPE Gateway Project Implementation Guide | Gateway Project Implementation Guide |
| CARESCAPE Hardwire and Wireless LAN Project Implementation Guide | Hardwire and Wireless LAN Project Implementation Guide |
| CARESCAPE Telemetry and Enterprise Access Project Implementation Guide | Telemetry and Enterprise Access Project Implementation Guide |
| Perioperative Products Project Implementation Guide | Perioperative Products Project Implementation Guide |
| Site Readiness QuickStart Guide for Innova | Innova Site Readiness |
| Site Readiness QuickStart Guide for PACS | PACS Site Readiness |
| Site Readiness QuickStart Guide for Mac-LAB & CardioLAB | Mac-LAB & CardioLAB Site Readiness |
| Site Readiness QuickStart Guide for Broadband | Broadband Site Readiness |
Your GE equipment has some typical accessories that compliment standard functionality. To appropriately address any questions, please contact your GE representative.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| AW Server | Connectivity Form XR | |
| Product | PreInstall Manual | |
| Advantage Workstation | 5719941-1EN Rev 7 | |
| Injectors for CT and PET | CT/PET Injectors | |
| Marking Lasers | Marking Lasers | |
| Express and AVIMOS Cameras for CT and PET | Positioning Cameras | |
| Fluoro Monitor | Fluoro Monitor | |
| Respiratory Gating System for CT and PET | Gating System | |
The ultrasound technology you've been looking for is here.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Connectivity Requirements | Connectivity Form Ultrasound |
| Product | |
| Echopac | Echopac |
| Invenia ABUS 2.0 | Invenia ABUS 2.0 |
| LOGIQ e | LOGIQ e |
| LOGIQ E9 | LOGIQ E9 |
| LOGIQ E10 | LOGIQ E10 |
| LOGIQ E10S | LOGIQ E10S |
| LOGIQ P7/P9 | LOGIQ P7/P9 |
| LOGIQ S7 | LOGIQ S7 |
| LOGIQ S8 | LOGIQ S8 |
| Venue | Venue |
| Venue Go | Venue Go |
| Versana Active | Versana Active |
| Versana Balance | Versana Balance |
| Versana Essential | Versana Essential |
| Versana Premier | Versana Premier |
| Vivid E80/E90/E95 | Vivid E80/E90/E95 |
| Vivid IQ | Vivid IQ |
| Vivid S60/S70 | Vivid S60 |
| Vivid T8/T9 | Vivid T8/T9 |
| Voluson E6/E8/E10 | Voluson E6/E8/E10 |
| Voluson P6/P8 | Voluson P6/P8 |
| Voluson S6/S8 | Voluson S6/S8 |
| Voluson S10 | Voluson S10 |
| Voluson SWIFT | Voluson SWIFT |
| Voluson SWIFT+ | Voluson SWIFT+ |
| Please note: if additional information is required, please refer to Chapter 2 - Site Preparation in the product service manual. All service manuals are available at the GE HealthCare Customer Documentation Portal. | |
Comprehensive solutions for your women's health services.
GE HealthCare has made reasonable efforts to ensure the pre-installation manuals on this Web portal are current and the drawings conform to requirements of the applicable pre-installation manuals. The drawings on this Web portal were produced to assist with site planning and are not intended for use as construction drawings. GE HealthCare is not responsible for any damages resulting from the use of such drawings for construction purposes. Compliance with all applicable local, state, and federal laws and regulations is the responsibility of the customer or its designated architect(s) and engineer(s). Please keep in mind the information in these pre-installation manuals and drawings is dynamic and is subject to change without notice. It is the responsibility of the customer or its designated architect(s) and engineer(s) to ensure they have the latest equipment or product information.
| Product | DWG | 3D PDF | BIM (Revit) | PreInstall Manual | Typical Final Drawing |
| Senographe Pristina | 9-38D | 9-38R | 9-38RV |
5729303-1-8EN | 9-38f |
| Senographe Crystal Nova | 9-40D |
6673206-8EN | 9-40f |
