Newborns in your care need your soft touch, your empathy, and your assurance that they will grow and develop, and go home healthy. The Panda Incubator helps provide reliable thermoregulation supported by technology that is easy to learn and use.

Reliable

Provides precise thermoregulation and humidification with Cascade Control (the same technology as used in Giraffe). To reduce admission wait times, the Panda Incubator ramps up in under 30 minutes, takes less than 5 minutes to recover its temperature from porthole openings and less than 15 minutes to recover when the door is opened2. The Panda Incubator also features dependable baby weight measurements for accurate thermal settings, and a UPS option for streamlined intra-hospital transport. ‘Steam and tubeless humidification’ (the same technology as used in Giraffe Incubator) helps to reduce bacterial growth and promotes effective cleaning.

Intuitive

Featuring a touch screen smartphone-like interface, context specific alarm help, and patient-based temperature suggestions, 96% of clinician’s report that they can confidently use the Panda Incubator after just 15 minutes of self-learning provided by the GE Helpbot1.

Flexible

Compact, easy to move, and equipped with handles on both ends, the Panda Incubator is ideally suited to managing a high volume of newborns in a crowded NICU or special care nursery. The rotatable display and dual access external tilt enables flexible bed positioning either parallel or perpendicular to the wall, maximizing your workspace.

Simple

Panda Incubator has up to 50% fewer parts to clean and is up to 41% faster to dissemble and reassemble compared to similar products in the market today¹.

Intuitive technology

The Panda Incubator’s technology is designed for reliability, efficiency, and workflow optimization, so the focus stays on the patients and not on the machine.

Autoclavable humidifier
Steam and tubeless humidification system enables fast and effective cleaning while providing precise protection through an additional level of sterilization.

Oxygen calibration
Advanced, reliable technology only requires recalibration annually.

Smartphone App
Smartphone AppAndroid & iOS compatible app for education, “quick tips,” service, cleaning videos.

Touchscreen display
Intuitive 7-inch color display designed to be similar to a smartphone interface, so staff can be trained quickly and focus their attention on patient care.

Set up and maintenance
Easy to install and maintain, the Panda Incubator ships fully assembled. Android and iOS compatible GE Helpbot app provides fast serviceability and cleaning tutorial videos.

Support
Encrypted USB and Ethernet port for quick trouble-shooting for service and maintenance

Transport
Optional UPS for streamlined intra-hospital transport.

Dimensions

• Height (fixed base option): 147 cm (57.8 in)
• Footprint: 60 cm x 116 cm (23.6 in x 45.7 in)
• Weight: 102 kg (without UPS option)
• Floor to mattress height (Fixed base option): 94 cm (37 in)
• Mattress size: 65 cm (25.6 in) and 36 cm (14.2 in) and 25.4 mm (1 in) thickness
• Mattress type: Removable, non-toxic, waterproof, radiolucent, washable
• Drawer size: 40 cm (15.7 in) x 39 cm (15.35 in) width and 19.5 cm (7.7 in) height
• Drawer load (Maximum): 7 kg
• Wheels: Double wheel with rotation and Swivel lock - 4.nos, Antistatic option available
• Opening angle of the doors: 180 degree
• Mattress to hood height: 36.1 cm (14.2 in)
• Portholes (number): 5
• Tubing grommets: 2 per each corner and 1 on north wall
• X-Ray tray: Compatible with a 17 in X 14 in X 1 in cassette
• Triple wall construction

Controller system

• Display: 7 in (17.78 cm), Capacitive touch, full color touch display, 800 x 480 pixels, 133 ppi
• Rotatable display: 180 degrees, horizontal axis
• Controller with LCD: With brightness control
• Selectable color combinations: Day and night modes
• Data collection: USB
• Trending: Set air temperature, actual air temperature, skin temperature, relative humidity, oxygen concentration, mode (baby or air) for one week with variable period range display; weight up to 14 measurements
• Alarm sound levels: Adjustable audible levels (50-65 dBa)
• Sound level: Max value <45dBa, when humidifier is running at 65% relative humidity (RH) and air mode set at 36± 1˚C at ambient of 25˚C
• Connectivity (service mode): USB
• Connectivity: Ethernet
• Comfort zone: A guide to setup optimal thermal environment for the patient
• Quick reference guide: Help section on device screen for quick reference
• Display brightness: Adjustable
• Mattress translation: 10 cm, Bi-directional
• Touch panel lock option: Yes, with display of key parameters
• Mattress tilt angle: +/- 15 degrees, continuously variable, tilt knob on both sides

In-bed scale performance (optional)

• Range: 300 g to 7 kg
• Accuracy:
  • Up to 2 kg: ± 2 g
  • From 2 kg to 7 Kg :± 5 g
  • Up to 2 kg (Europe - Optional NAWI Scale): ± 5 g
  • From 2 kg to 7 kg (Europe - Optional NAWI Scale): ± 10 g Resolution : 1g ,2g ,5g,10 g (for Non-EU scale)10 g (for EU scale)

Servo oxygen control performance (optional)

• Control range: 21-65% with 1% increment
• Display range: 16% to 70% with ± 5% accuracy and1% display resolution
• Rise time: <10 minutes from 5% below set point
• Recovery time: < 10 minutes fromclosing porthole or door to 5% below set point
• Alarms: ±3% from set point
• Control Accuracy: ± 5%
• Inlet pressure maximum: 46 psi to 87 psi (320 kPa to 600 kPa)

Battery backup (optional)

• Backup period: 20 minutes (when unit is operated in Airmode at air set temp of 36°C and ambient 25°C)
• Battery visual indicator on display: Yes
• Battery backup: 1 Kva

Operating environment

• Temperature: 20-30˚C
• Humidity: 10-95% relative humidity (non-condensing)
• Altitude: MSL to 7,900 ft (2,408 m) or 755 hPa
• Air velocity: Up to 0.3 m/sec
• Water Ingress: IPXO

Device classification

• Protection class: Class 1, Type B, continuous operation
• Ingestion of liquids: IPX0

Thermal performance

• Baby (servo) temperature control: 34˚C to 37.5˚C in 0.1˚C increments with override >37˚C
• Baby (servo) temperature display: 30˚C to 42˚C in 0.1˚C increments with ± 0.3˚C accuracy
• Air temperature control: 20˚C to 39˚C in 0.1˚C increments with override >37˚C
• Air temperature display: 15˚C to 45˚C in 0.1˚C increments with ±0.3˚C accuracy
• CO ² level: <0.3%
• Micro filter air intake : 99.8% efficiency
• Particle size removal: 0.3 micron
• Warm up time: <30 minutes (Ambient 25˚C, 36˚C)
• Recovery from open portholes (2): 5 min
• Recovery from open door (1): <15 min
• Temperature overshoot: As per IEC, 60601-2-19 standard
• Temperature uniformity with a level mattress: <0.6˚C
• Correlation of the indicated air temperature to the actual incubator temperature: ±0.8˚C
• Air boost: Yes, user selectable

Humidifier performance

• Reservoir capacity: 1600 mL
• Reservoir type: Transparent
• Humidification technology: Steam humidification, Tubeless system
• Operating time between refills: 24 hours at 65% control setting at 36˚C air mode at ambient condition of 25˚C and 50% relative humidity (RH)
• Servo humidity control range: 30-95% RH in 1% increments
• Servo humidity display range: 5-99% RH in 1% increments, with ±10% accuracy and min 75% for setting >85%
• Humidity display accuracy: ± 10% RH (between 10% and 90% at 20˚C to 40˚C
• Control accuracy: ±10%
• Alarm: Water out alarm
• Ramp up time: <=50 minutes for time to reach 75% RH with a 39˚C control temp from cold start in 25˚C, 50% RH room
• Recovery time: <20 minutes

Elevating base (optional)

• Floor to mattress height (range) for elevating base option: 79 cm (31 in) to 109 cm (43 in)

Additional power source

• Additional power source: Up to 30W forLullaby ^TM LED Phototherapy

Service and maintenance

• Recommended preventive maintenance period:
  • Humidity sensor: Once every four years
  • Oxygen sensors: Annual Warranty: To better suit your needs we offer customizable warranty programs, maintenance contracts, and repair options to reduce total cost of ownership

Storage / shipping information

• Temperature: -25 to 60°C
• Humidity: <=85% relative humidity (non-condensing)
• Pressure: 50-106 kPa

Optional accessories

• Monitor shelf
• Tubing management arm
• Fabric canopy cover
• IV pole
• HFOV port hole cover

Consumables

• Air filter package (Pack of 10)
• Grommet seal package (Pack of all grommets of 1 No. each)
• Patient restraint strap (pack of 5)
• Disposable patient probe (pack of 10)
• Heat reflecting patch (pack of 50)
• Shelf restraint strap (pack of 2)
• Water Reservoir assembly
• Reusable patient probe
