To enhance spatial resolution

The Clarity Imaging Chain was completely redesigned for Revolution EVO Gen 2 to deliver high spatial resolution, so you can clearly see details as small as 0.28 mm.

The Clarity Imaging Chain features:

• The Performix 40 Plus tube with its stable dual focal spot for better precision and its 0.35-second routine rotation speed for faster scan times.
• Highlight Clarity detector inherited from the breakthrough technology introduced on Revolution CT.

To make low dose routine or improve imaging quality

ASiR-V* is our novel iterative reconstruction technology. It has been designed to reduce noise levels, improve low-contrast detectability and reduce dose in routine imaging.¹

Help you improve productivity

Designed to help you improve productivity by streamlining your workflow and access to information, Smart Flow technologies enable fast, hands-free patient positioning, exam prescription from the patient’s side, integrated injections, real-time reconstruction up to 55 images during the scan with Image Check and access to advanced applications right on the console. With the IQ Enhance pitch booster, you can scan a chest in as fast as two seconds with 175 mm per second acquisition speed to help shorten patient breath-holds while maintaining image quality.

Revolution EVO Gen 2 features intelligent technology designed to help you acquire high-quality images using lower doses of radiation, contributing to more accurate diagnoses and lower exposures for patients. Dose management tools such as CT 4Kids dose-optimized pediatric reference scan protocols, 3D Dose Modulation, Organ Dose Modulation, Dose Check, DICOM DRSR and more are all at your fingertips. Revolution EVO Gen 2 is also compliant with NEMA XR 25 and XR 29 standards.

Set up complex cardiac procedures quickly, reliably, and repeatedly, with Smart Cardiac tools are available on the Advantage Workstation*.

SnapShot Assist: Easily complete cardiac exams in as few as five beats with SnapShot Assist, which advises you of the best acquisition technique based on the patient’s heart rate and BMI.

SnapShot Pulse: Prospective gating with SnapShot Pulse allows for significant dose reduction in coronary imaging as compared to an ECG-gated helical acquisition mode.

SnapShot Freeze²: Reducing motion blurring in vessels by up to a factor of six, SnapShot Freeze facilitates your diagnosis by freezing coronary motion even in higher-heart-rate coronary CT exams. It delivers a 58 msec-equivalent gantry speed with an effective temporal resolution of 29 msec3.

Dual-energy imaging allows easy configuration of back-to-back axial or helical scans of the same anatomy at two different X-ray energies (kVs).

The dual-energy data can be quickly post-processed right on the console or on the Advantage Workstation with easy image registration and one-click ROI ratio for simple analysis.
